How to Draw a Fence Site Plan for Florida Permits
A fence permit can stall over a sketch that leaves out one number. That happens a lot, even when the fence itself is simple.
A fence site plan for Florida permits does not need to look polished. It needs to show your lot, your fence, and the measurements a reviewer can trust. When the drawing is clear, the permit process gets easier.
Start With a Survey or Recorded Plat
The best base for your drawing is a current property survey. If you have one, use a copy and keep the original clean. The survey gives you the lot outline, corner points, and often easements or setback lines.
If you do not have a survey, check whether your local permit office will accept a recorded plat or a simple dimensioned site plan. Some will. Others will want a survey, especially if the fence sits close to a property line or easement. That is why it helps to confirm the rules before you spend time sketching.
If you're in unincorporated Lee County, the Lee County fence permit site plan requirements page is a useful check. County rules can add extra paperwork, so the details matter.
Trace the lot shape from the survey onto clean paper or into a simple digital drawing. Keep the line work plain. You are not trying to make art. You are building a map the reviewer can read in seconds.
If the permit reviewer cannot measure it from your plan, expect a correction request.
Draw the Lot and Fixed Features
Once you have the lot outline, add the things that do not move. That includes the house, driveway, sidewalks, shed, pool, well, septic tank, air-conditioning unit, and any other permanent structure on the property.
A simple plan works best when it shows the whole picture. Use a scale that fits the lot on the page, then add a north arrow and the street name. If the lot is a corner lot, label both street sides. Reviewers pay extra attention there.
Here's a quick list of the basics that belong on the page:
| Plan element | What to show | Why it matters |
|---|---|---|
| Property lines | All sides with measurements | Confirms the fence stays on your lot |
| House and structures | Home, pool, shed, driveway, walkways | Shows clearances and layout |
| North arrow and scale | Direction and drawing scale | Makes the plan readable |
| Street side | Road name and which side faces the street | Helps identify corner and front-yard rules |
| Easements or notes | Drainage, utility, or access areas | Keeps the fence out of restricted space |
That table should help you see the goal. The plan is not just a picture, it is a measured snapshot of the property.
After you draw the fixed features, check that the measurements match the survey. If the survey shows a side yard as 72 feet, write 72 feet on the plan. Do not round unless your permit office says rounding is fine.
Show the Fence Line and Every Measurement
Now draw the proposed fence in the exact spot you want it installed. Use a solid line or a clearly marked outline. If the fence turns a corner, show the turn. If it has gates, show each gate opening and which way it swings.
The fence line should be easy to follow from start to finish. A reviewer should be able to trace it without guessing. That means no faded lines, no missing segments, and no vague labels like "fence here."
Label the distance from the fence to the closest property lines. If the fence sits inside the lot instead of on the line, show that offset in feet. If it runs near a pool, patio, or wall, add those clearances too.
Use plain notes for the fence details:
- Fence height, such as 4 feet, 5 feet, or 6 feet
- Fence material, such as vinyl, wood, chain link, aluminum, or metal
- Gate locations and gate swing direction
- Any section that changes height or style
A clean note can look like this: "6-foot white vinyl privacy fence, with one 4-foot gate on the side yard, gate swings inward." That kind of description helps a reviewer match the drawing to the permit application.
If your fence follows a setback line or stays clear of an easement, mark that clearly. Do not leave the reviewer to guess where the fence starts and stops.
Match the Drawing to Local Permit Rules
Florida does not use one single fence rulebook for every address. City and county building departments can ask for different submittals, and that matters more than most homeowners expect. Some offices want a site plan to scale. Some want a survey with the fence line marked on top. Others want both.
That is why you should confirm the exact fence height, setback, easement, and survey requirements with your local permitting office before you submit anything. A drawing that works in one city may get sent back in the next county over.
If you live in Sarasota County, the Sarasota County fence permit basics page shows the same core idea, a clear plan plus the right parcel details. The office wants to see what you are building, where it goes, and how it fits the lot.
Keep this in mind when you review your own sketch:
- Taller fences may trigger extra review.
- Easements can affect where the fence can go.
- Corner lots can have visibility limits.
- Water, drainage, and flood areas can change the layout.
- Some offices want the fence line marked on a survey, not just drawn freehand.
A clear plan saves time because it answers questions before the reviewer has to ask them.
Common Mistakes That Slow Down Fence Permits
Most rejected fence plans miss small things, not big ones. The drawing might be neat, but it leaves out the numbers that matter. If you want fewer delays, check for these issues before you submit.
A neat sketch can still fail if it leaves out measurements, easements, or fence height.
If your project is in Collier County, the Collier County fence permit basics page is a good reminder of what reviewers want to see on the page.
Watch for these common problems:
- The plan has no scale or north arrow.
- Property lines are not labeled.
- The fence line crosses an easement by mistake.
- Fence height or material is missing.
- Gate locations are shown, but the swing direction is not.
- Measurements on the sketch do not match the survey.
- The drawing is too faint to read after scanning or copying.
If you catch one of those before submission, fix it right away. Small edits are much easier than a full resubmittal.
One more point helps a lot. Use a dark pen or a clean digital file, and leave enough space around each measurement. Crowded notes are hard to read, and hard-to-read plans slow everything down.
Conclusion
A permit-ready fence drawing is simple when you break it into pieces. Start with a current survey or plat, copy the lot clearly, then add the house, structures, fence line, and full measurements. The plan should tell the reviewer exactly where the fence goes and what it will look like.
The biggest mistake is guessing. If a local office wants a survey, a specific setback, or an extra note for an easement, that rule wins every time.
A clear, dimensioned site plan gives your fence project a better chance of moving forward without a round of corrections.
